Description
The LZZBJ9-10 Current Transformer is a high-quality, epoxy resin cast, fully enclosed bushing-type transformer designed for 10kV and below power systems with a rated frequency of 50Hz or 60Hz. It is specifically engineered for energy measurement, current monitoring, and electrical protection applications.
Key Features:
-
Robust Insulated Structure: Fully encapsulated in epoxy resin for superior electrical insulation, mechanical strength, and environmental protection against moisture, dust, and corrosion.
-
High-Precision Core and Windings: Made from premium cold-rolled silicon steel sheets with carefully wound primary and secondary coils, ensuring accurate current measurement and minimal loss.
-
Wide Application Range: Rated primary currents from 5A up to 2000A and secondary currents of 1A or 5A. Suitable for various measurement and protection accuracy classes (0.2, 0.5, 5P, 10P).
-
Reliable and Safe Operation: Secondary winding grounding ensures protection against high voltage backflow. Strict adherence to safety during installation, operation, and maintenance prevents operational hazards.
-
Durable and Weather-Resistant: External housing made from high-strength plastic or metal with excellent mechanical durability, suitable for outdoor or indoor installations.
Technical Highlights:
-
Rated Voltage: 10kV
-
Rated Frequency: 50Hz or 60Hz
-
Insulation Levels: 42kV power frequency withstand, 75kV lightning impulse withstand
-
Accuracy Class: Measurement (0.2, 0.2S, 0.5, 0.5S), Protection (5P, 10P)
-
Wide temperature and humidity tolerance: -25°C to +40°C, relative humidity up to 95% daily
Easy Installation & Maintenance:
Designed with user-friendly mounting holes and terminals for quick setup. Routine checks include insulation resistance, temperature monitoring, and ratio verification to ensure long-term reliability.
Why Choose LZZBJ9-10:
Perfect for industrial substations, power plants, and commercial energy monitoring systems, the LZZBJ9-10 combines accuracy, safety, and durability to support high-performance electrical measurement and protection needs.
